SVS SoundPath Ultra Speaker Cable
SVS SoundPath Ultra Speaker Cable

Innovative Three-layer Insulation System Adds Durability And Enhances Electrical Insulation And Signal Purity
- Precision machined and anodized aircraft grade aluminum body.
- Finely woven premium cotton braided jacket adds styling and serves as the durable, outermost boundary to protect against physical wear and tear.
- A 3-layer shielding system, including 3.2mm and 7.6mm PVC dielectric cores protects each conductor.
- Precision machined brass body with electroplating finish for a solid build and substantial feel.
What’s The Difference Between SVS Soundpath One And SVS Soundpath Ultra Speaker Cables?
SVS Soundpath Speaker Wire comparison | Ultra | One |
---|---|---|
Custom, Metal Stranding and Annealing Process to Maximize Ductility and Strength | x | x |
99.99%, OSD Oxygen Free Copper For Pristine Signal Transfer, High Dynamic Range and, Exceptional Conductivity | x | x |
Insulated, Dielectric Outer Shell | x | x |
Rounded, Cable Design for Easy Termination and Cable Separation | x | x |
High, Tensile Protective Braided Sleeve for Insulation, Easy Handling and Superior Durability | x | |
Dual-Layer, Dielectric Shielding for Added Durability, Enhanced Electrical Insulation and Signal Purity | x | |
Custom, Hand-Terminated with Individually Soldered Banana Plugs, Spades or, Combination of Both | x |
SoundPath Ultra Speaker Cable Specs:
- 14 AWG stranded speaker wire – Each SoundPath Ultra Cable is made with two braided Dual Balanced conductors, with a total of 82 strands of 99.99% pure stranded copper across both conductors.
- Precision machined and anodized aircraft grade aluminum body - stylish and durable with a great feel and easy handling.
- PVC dielectric joint - Flexible and durable break-out for Positive and Negative terminals.
- Rated Bandwidth = DC-5.0 MHz (3M cable) with ≤1.1 Voltage Standing Wave Ratio (VSWR) and ≥26dB Return Loss.
- Conductor DCR = 8 mΩ/meter
- Nominal Impedance = 90Ω - Cable and connectors are impedance-matched to minimize VSWR and Return Loss
- Nominal Capacitance = 68pF/meter @ 1kHz
- Nominal Cable Diameter: 9mm
